The Realkey Fire Disconnect Conveyor (RKMODU-FDC) is an automated device specifically designed for fire safety and emergency rescue situations in logistics centers, production workshops, and similar environments. It is typically installed on conveyor lines that span fire shutters, passages, corridors, or other critical locations and is integrated with the fire protection system. In the event of a fire or other emergency, it can automatically and quickly retract to provide space for the fire shutters to descend, thereby isolating the hazardous area or opening a passage for rescue personnel to enter the fire scene.
For detailed information about the Realkey Fire Disconnect Conveyor (RKMODU-FDC), please refer to the product description below or directly consult Realkey customer service personnel.
Rapid Response
Interlinked with the fire protection system, it automatically activates in emergencies, gaining valuable time for early fire prevention.
Flexible Retraction
Equipped with high-strength retractable arms, it can quickly and automatically retract as needed, with adjustable distance.
Safe and Reliable
Made with insulating materials, it can operate normally even in humid or smoky environments.
Intuitive Indication
Equipped with LED indicator lights and an audible alarm system.
Equipment Model
RKMODU-FDC
Equipment Length
(Fixed Section) 1400 mm + (Retractable Section) 600 mm, customizable according to actual needs
Effective Width
1000/1200/1400 mm, customizable according to actual needs
Conveyor Speed
0.2-90 m/min
Drive Type
Electric Drum
Rated Load
60 kg/㎡
Ambient Temperature
-20~40 ℃
Ambient Voltage
Three-phase five-wire 380V
Equipment Accessories
Can be equipped with protective plates, bottom sealing mesh, photoelectric switches, and other accessories as needed
OEM/ODM
Support for customized design and manufacturing according to customer requirements
